cs4140 Notes: 08-04 Core Workflow

• Issue
  • Clear Description
  • Acceptance Criteria (how to manually confirm resolution)
• Do the work
  • Issue assigned to Alice
  • Personal fork
  • Local clone
  • Feature branch
  • Work on feature branch locally
  • Automatic tests first, initially failing due to the issue
  • Write code to solve the problem
  • Automatic tests pass now
  • Manual testing confirms acceptance criteria met
  • Push branch to personal fork on Github
  • Create PR from branch to main repo
• Review
  • The PR is a new issue
  • It gets assigned to someone else, Bob (Bob is not Alice)
  • Bob confirms that tests are passing (optimally in CI)
  • Bob reads the issue, pulls the feature branch down locally, manually tests for the acceptance criteria
  • Bob hits the code review button on Github
    • Read every line of modified code
    • Are the changes related to the issue?
    • Are the changes reasonable? (style, approach, efficiency, security, etc)
    • Problems: Comments in Github UI, ping to Alice
  • Once the PR is good, bob hits “Squash and Merge”
  • After the merge, Bob confirms that CI still passes. If not, revert.

We’ll walk through this for adding a new card.

• The card list lives in shared/cards.ts
  • The list itself is just a single immutable global, cards
  • Currently we build a list of 60 unique cards out of a pool of two, so we generate a bunch of distinctly named copies.
  • To add a new card, we add it to the list.
• We’re going to add “zap”, which does one damage to an opposing bot.

const zap: Omit<Card, "name"> = {
	type: "action",
	atk: 0,
	hp: { current: 0, max: 0 },
	status: [],
	effect: { kind: "damage", amount: 1 },
};

/** The master list of all cards in the game. Never mutated at runtime. */
export const cards: Card[] = [
	...range(10).map((n) => ({ ...duck, name: `Robot Duck ${n}` })),
	...range(30).map((n) => ({ ...repair, name: `Light Repair ${n}` })),
	...range(20).map((n) => ({ ...zap, name: `Zap ${n}` })),
];

That gives us a type error, saying “damage” is not assignable. We’ve got to go look in shared/types.ts

Looking at the CardEffect type, damage sounds like it’s structurally similar to repair, so:

export type CardEffect =
  | { kind: "repair"; amount: number }
  | { kind: "damage"; amount: number };

That fixes the type issue.

Then we need to actually implement the effect in server/gameplay.ts:

function applyEffect(
	effect: NonNullable<GameCard["effect"]>,
	boardOwner: GamePlayer,
	slot: number,
): void {
	const bot = boardOwner.board[slot];
	if (!bot) return;
	if (effect.kind === "repair") {
		bot.hp.current = Math.min(bot.hp.max, bot.hp.current + effect.amount);
	}
	if (effect.kind === "damage") {
		bot.hp.current = Math.max(0, bot.hp.current - effect.amount);
	}
}

That’ll stop being good style quickly once we have a couple more effects, but this works for now.

Zap Illustration

Picture goes in public/images

Then we’ve got to hook up the browser logic:

• src/cardImages.ts, add to the map.

That should be everything. pnpm dev to test it.

Once it seems to work:

git add -A .
git status # check what we added, only the files we meant to add
git commit -a -m 'add zap'
git push

On Github:

• Create PR

Now, a different person needs to do the next step:

• Read every line of modified code
• Are the changes related to the issue?
• Are the changes reasonable? (style, approach, efficiency, security, etc)
• Problems: Comments in Github UI

How do we figure out where stuff is if we really have no idea?

#

Introduce OpenCode
